PV1- F 2*4.0mm2
Electric Characters
Voltage rating:0.6/1kV
Temperature rating:120℃
Dielectric strength:AC-6.5kV/1 sec MIN
Spark test:AC-10kV/In the air
Conductor resistance：5.35ΩKM Max at20℃
Weathering/UV-resistance:720h，No cracking
Thermal endurance properties: 25 Years
Physical Properties
Elongation of unaged values:≥125%
Tensile strength of unaged values:≥ 6.5&8.5
Aged in a full draft circulating air oven:150±2.0℃/168h
Elongation of After aging:≥70%
Tensile strength of After aging：≥70%
Ozone resistance:72h No cracking
Cold bend test: -40±2℃*16h No cracking
Cold impact test:-40℃*16h/1000g；100mm No cracking
Flame test:EN60332-1-2
